Technical specifications
Film width: Max.240mm
Bag length:
Double knives: 65-190mm/90-220mm
Single knives: 120-280mm/150-330mm
Products height: 1-55mm
Film roll diameter: max.320mm
Packing speed: 40-230bags/min
Power specification: 110V/220V/380V 50/60HZ 2.4KW
Machine size : (L) 3770 * (W) 670 * (H) 1400 mm
Machine weight: 370KG
Afer-sales service
1. Each machine with the relevant English operating instructions.
2. Our engineers can operate through a video demonstration.
3. professional engineers will answer the techonical questiones at wroking time by phone call or WhatsApp or other tools.
4. Sending engineer to overseas for installation and training is agreed.
The feature of the Packing machine
1.Cross seal and middle seal are controlled by independent motor. With simple mechanical structure, stable operation, and low noise.
2.High speed, high accuracy, the maximum speed can be up to 230 bags / min.
3.Human machine interface,convenient and smart parameter settings.
4.Automatic fault diagnosis function,fault displayed clearly.
5.Color tracking, digital input seal cutting position, make the seal cutting position more accuracy.
6.Double supporting paper structure, automatic film connecting device, simple film changing , quick and accuracy.
7.All controls can be implemented by software system, facilitate functional tuning and technical upgrading, and never fall behind.
